8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F2.03
Motor rated
rotation speed
0~36000rpm 1rpm
Different
according
to
inverter
model
●
F2.04
Motor rated
voltage
0~480V 1V
●
F2.05
Motor rated
current
0.8~2000A 0.1A
●
F2.06
Motor stator
resistance
0.001~65.53Ω 0.001Ω
○
F2.07
Motor rotator
resistance
0.001~65.53Ω 0.001Ω
○
F2.08
Motor stator
inductance
0.1~6553mH 0.1mH
○
F2.09
Motor rotator
mutual
inductance
0.1~6553mH 0.1mH
○
F2.10
Motor no-load
current
0.1~655.3A A
○
F2.11
Motor
parameters
autotuning
0:No autotuning
1:Autotuning completely(no load)
2:Static autotuning(with load)
0
●
F2.12 Reserved
F3 Group: Vector Control Parameters
F3.00
Proportional
gain 1 of speed
loop
0~100 20
○
F3.01
Integral time 1
of speed loop
0.01~10.00s 0.01s 0.50s
○
F3.02
Low frequency
point of switch
0.00Hz~F3.05 0.01Hz 5.00Hz
○
