SAJ 8000B series - F6 Group: Output Terminals Parameters

-
47
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F5.21
ACI upper limit
corresponding
to setting value
-100.0%~100.0% 0.1% 100.0%
○
F5.22
ACI input filter
time
0.00s~10.00s 0.1s 0.10s
○
F5.23
~
F5.32
Reserved
F6 Group: Output Terminals Parameters
F6.00
MO1 output
selection
0:No output
1:Motor forward running
2:Motor reverse running
3:Fault output
4: Frequency detecting level
FDT output
5:Frequency reached
6:Running at zero speed
7:Upper limit frequency reached
8:Lower limit frequency reached
9:Frequency setting value less
than lower limit frequency
10:FDT reached
11:Accumulative running time
reached
12:PLC cycle completed
13:Pre-alarm when overload
14:User define output
15:Running frequency detection
16:Terminal input delay
17:Inverter stand-by
1
○
F6.01 Reserved 0
○
F6.02
Relay 1 output
selection
3
○
F6.03
Relay 2 output
selection
0
○
