SAJ 8000B series User Manual

-
49
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F6.12
AM output
upper limit
0.0~100.0% 0.1% 100.0%
○
F6.13
AM upper limit
corresponding
to output
0.00V~10.00V 0.01V 10.00V
○
F6.14
User defined
output
variability option
(EX)
0:Running frequency
1:Setting frequency
2:DC bus voltage
3:Output current
4:Output voltage
5:Sign of start and stop status
6:Sign of control status
7:Counter value
8:Counting meter value
9:Inverter module temperature
10:AVI input value
11:ACI input value
0
○
F6.15
Comparison
method of user
defined output
Un it s d ig it: c om pa ri so n te st
method
0: equal (EX==X1)
1: equal or greater than
2: equal or less than
3 : i n t e r v a l c o m p a r i s o n
(X1≤EX≤X2)
4:units digit test (EX&X1=X2)
Tens digit : output method
0 : false value output
1: real value output
00
○
F6.16
User defined
dead interval
0~65535 0
○
F6.17
Output
comparison
value X1
0~65535 0
○
F6.18
Output
comparison
value X2
0~65535 0
○
