SAJ 8000B series User Manual

-
45
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F5.02
M3 terminal
function
13: Frequency setting source
switch between X and Y
14: Frequency setting source
switch between X and (X+ Y)
15: Frequency setting source
switch between Y and (X+ Y)
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: Acceleration/deceleration
time selection terminal 1
22: Acceleration/deceleration
time selection terminal 2
2 3: R e se t s i mp l e P LC a f t er
pause
24: Simple PLC pause
25: PID pause
26: Swing frequency pause (stop
at current frequency)
27: Reset after swing frequency
p a u s e ( r e s e t t o c e n t r a l
frequency)
28: Counter reset
29:Reserved
30:Acceleration /deceleration
prohibited
31:Counter triggering
3 2: C le a r U P/ D O W N s et t ing
temporarily
33: Reserved
34: Counting meter input
35: Counting meter clear up
36: Command source switch
37: Terminal input delay output
38: Reserved
7
●
F5.03
M4 terminal
function
0
●
F5.04
M5 terminal
function
0
●
F5.05
M6 terminal
function
0
●
