4. Check preferences dialog to be sure the calibration data is loaded.
5. Close the software.
6. Copy all *.cal files from the calibration folder of that computer to the computer without Internet
access.
Each .cal file is specific to a single device, but the .cal files are saved with the device ID in decimal and
not hex, making it hard to tell which is which. If only one device has ever been connected, there will only
be one .cal file.
Is Periodic Recalibration Required?
Our devices do not require periodic recalibration.
Having Trouble?
If you are having trouble manually downloading the calibration file, we can send it to you. Please contact
support, and we can make sure your calibration data gets updated.
