Saving and Loading Software Settings
The software settings can be saved and loaded at a later time, allowing the user to recall a particular
setup. This is especially useful when jumping back and forth between multiple test setups. See: Saving
and Loading Software Settings
Reducing Capture File Disk Usage
The file size of a capture file (.logicdata file) can be significantly reduced by zipping it to a compressed
folder. This is especially useful when sending your capture file over the network.
