Supported digital measurement calculations:
• Width (for persistent measurements, this is the time span of the measurement)
• Frequency (this is just 1/width)
• Average Frequency (average frequency of all complete cycles inside the range)
• Average Duty Cycle (average duty cycle of all complete cycles inside the range)
• Count of Rising Edges
• Count of Falling Edges
• Count of Positive Pulses
• Count of Negative Pulses
• Minimum Positive Pulse Width
• Maximum Positive Pulse Width
• Minimum Negative Pulse Width
• Maximum Negative Pulse Width
• Period (for persistent measurements, this is the time span of the measurement)
• Average Period (average period of each complete cycle in the range)
• Count of Complete Periods (Cycles)
Supported analog measurement calculations:
• Width (for persistent measurements, this is the time span of the measurement)
• Frequency (this is just 1/width)
• Period (this is the same as the width for persistent measurements)
• Min-Max Voltage (displays both the minimum voltage and the maximum voltage in a range)
• Start Voltage (the voltage at the start of the span)
• End Voltage (the voltage at the end of the span)
• Delta Voltage (Abs (Start-End))
• Peak to Peak Voltage (Max-Min)
