What's In the Box?

• Logic 8 includes: Saleae Logic 8 USB Logic Analyzer, 2x 4-Channel Wire Harnesses, 16x Micro-

Gripper Hooks, Saleae Carrying Case, USB 2.0 Micro Cable, & the Getting Started Card

• Logic Pro 8 includes: Saleae Logic Pro 8 USB Logic Analyzer, 2x 4-Channel Wire Harnesses, 16x

Micro-Gripper Hooks, Saleae Carrying Case, USB 3.0 Cable, & the Getting Started Card

• Logic Pro 16 includes: Saleae Logic Pro 16 USB Logic Analyzer, 4x 4-Channel Wire Harnesses, 32x

Micro-Gripper Hooks, Saleae Carrying Case, USB 3.0 Cable, & the Getting Started Card

Purchasing Additional Accessories

Several additional accessories, which are not included in the box, can be purchased via the Saleae

Accessories store.
