Product Summary
Saleae Logic Analyzers consists of the products listed in this section. The 2nd Generation of products
have the capability of recording both digital and analog signals, while the 1st Generation of products have
digital recording capability only.
1st Generation:
• SALEAE001 Logic (Discontinued)
• SALEAE009 Logic16 (Discontinued)
2nd Generation:
Note: "Red" or "Black" is not written on the device. This refers to the color of the device enclosure. The
specific device model is written on the bottom of the device enclosure.
• SAL-00109 Logic 4 Black (Discontinued)
• SAL-00110 Logic 4 Red (Discontinued)
