CO2: Heating circuit Rk2 (Systems Anl 3.0-3.4, 4.x and 10.0)*
F Function WE Anl
Comments
Function block parameters/Range of values (default setting)
01 Room sensor RF2 0 All* CO2 -> F01 - 1: Temperature display and input FG2 for
Type 5244/5257-5 Room Panel active
TROVIS 5570 Room Panel:
CO2 -> F01 - 1 and CO7 -> F04 - 1
02 Outdoor sensor
AF2
0 All* Without measured value AF2, the value AF1 is read
Measured value AF2 only over device bus:
CO2 -> F02 - 1 and CO7 -> F09 - 1
03 Return flow sensor
RüF2
1 10.0 CO2 -> F03 - 1: Sensor and limiting function active
Function block parameter:
Limiting factor / 0.1 to 10.0 (1.0)
0 3.0, 4.x
04 Reserved
05 Underfloor heating
Drying of jointless
floors
0 All* CO1 -> F05 - 1: Limitation of the adjustment ranges
Function block parameters:
Temperature rise / 1 to 10 °C/24 h (5 °C/24 h)
Maximum temperature / 25 to 60 °C (45 °C)
Maintaining time of max. temperature/1 to 10 days (4 days)
Temperature reduction / 0 to 10 °C/ 24 h (0 °C / 24 h)
START
06 Reserved
07 Optimization 0 All* CO2 -> F07 - 1: Only with • CO2 -> F01 - 1
• CO1 -> F02 - 1
08 Adaptation 0 All* CO2 -> F08 - 1: Only with • CO2 -> F01 - 1
• CO1 -> F02 - 1
• CO2 -> F11 - 0
09 Flash adaptation 0 All* CO2 -> F09 - 1: Only with CO2 -> F01 - 1
Function block parameter:
Cycle time / 1 to 100 min (20 min)
Gain K
p
/ 0 to 25 (0)
10 Reserved
11 4-point
characteristic
0 All* CO2 -> F11 - 1: 4-point characteristic, only with
CO2 -> F08 - 0
CO2 -> F11 - 0: Gradient characteristic
104 EB 5575 EN
Appendix
