1.8 Activating extended operating level
After the key number 1999 has been adjusted, the following information can be viewed and
edited after the data points listed in section 1.4 have been displayed:
4
Flow rate
4
Heat capacity
4
Public holidays “ “ (editable)
4
Vacation periods “ “ (editable)
4
Valve positions
4
Switching states of the binary inputs
4
Info 2 · The following data are shown in the same sequence as shown below:
Controller ID
Memory capacity of data logging module (section 9.1)
255
Operating hours of solar circuit pump (refer to section 6.4)
Water flowmeter (refer to section 6.3)
Opening the extended operating level:
Switch to configuration and parameter level.
Display shows:
0 0 0 0
q
Set key number 1999.
Confirm key number.
Display shows: time
Note!
The additional information is no longer displayed when the key number 1999 is adjusted
again.
16 EB 5575 EN
Operation
