Samson TROVIS 5575 - Assignment of the Rotary Switches

12.3 Assignment of the rotary switches
System Anl Top rotary switch Middle rotary switch Bottom rotary switch
1.0 Heating circuit Rk1
––
1.1 to 1.3 Heating circuit Rk1
– DHW heating
1.5, 1.6
Primary heat exchanger
circuit Rk1
– DHW heating
1.9 –
– DHW heating
11.x –
– DHW heating
2.x Heating circuit Rk1
– DHW heating
3.0
Primary heat exchanger
circuit and heating circuit
Rk1, Rk2
––
3.1 and 3.2
Primary heat exchanger
circuit and heating circuit
Rk1, Rk2
– DHW heating
3.5
Primary heat exchanger
circuit Rk1
––
4.x
Heating circuit Rk1
Supplementary heating circuit Rk2 DHW heating
10.0 Heating circuit Rk1
Heating circuit Rk2 –
11.x Heating circuit Rk1
– DHW heating Rk2
EB 5575 EN 121
Appendix
