3 Manual operation
Switch to manual operating mode to configure all outputs (see wiring diagram in sec
-
tion 11).
Manual operation for the different control circuits is adjusted at the rotary switches:
Manual operation Rotary switch Position
Heating circuit 1* Top
Heating circuit 2* Middle
DHW circuit* Bottom
* Refer to page 121 for assignment
Proceed as follows:
Turn appropriate rotary switch to “Manual operation“.
q
Select:
POS_ : Correction value in percent
UP_: Activation of the circulation pump
SLP: Activation of the storage tank charging pump
Confirm selection.
Display blinks.
q
Edit the correction value or activate/deactivate the circulation pump etc.
Confirm edited settings.
The modified values remain active as long as the controller is in manual mode.
Return the rotary switch to the desired operating mode (left side).
Manual operation of the selected control circuit is deactivated by switching to any other
operating mode.
Note!
Simply setting the rotary switch to “Manual operation“ does not have any affect on the
outputs. You have to actually enter a correction value or activate/deactivate the pumps to
configure the outputs.
In manual operating mode, frost protection (–> section 7.2) is not activated.
