2 Start-up
The modifications of the controller configuration and parameter settings described in this sec
-
tion can only be performed after the valid key number has been adjusted.
The valid key number for initial start-up can be found on page 134. To avoid unauthorized
use of the key number, remove the page or make the key number unreadable. In addition, it
is possible to adjust a new, customized key number (–> section 7.15).
2.1 Setting the system code number
21 different hydraulic schemes are available in the TROVIS 5575-000x standard version
and in the TROVIS 5575-002x version. The TROVIS 5575-001x version has two additional
hydraulic schemes. Each system configuration is represented by a system code number. The
different schematics are dealt with in section 4. Available controller functions are described
in sections 5, 6 and 7.
Changing the system code number resets previously adjusted function blocks to their default
values (WE). Function block parameters and parameter level settings remain unchanged.
The system code number is adjusted in configuration level.
Proceed as follows:
Switch to configuration and parameter level.
Display shows:
0 0 0 0
q
Set valid key number.
Confirm key number.
Display shows:
PA1
q
Select Anl.
Activate editing mode for the system code number.
q
Edit system code number.
Confirm system code number.
Display shows:
End
Return to operating level.
