F Function WE Anl
Comments
Function block parameters/Range of values (default setting)
10 Flow rate limitation
(capacity limitation)
in Rk1 with pulses
at input WMZ
0 Not in Anl
1.9, 10.0;
not in
systems
with
SF2/RF2
CO5 -> F10 - 1 only with CO5 -> F11 - 0
Input “WMZ/Bed“ (terminals 03/13)
Function block parameters:
Max. limit value / 3 to 500
pulse
h
(15
pulse
h
)
Max. limit value heating* / 3 to 500
pulse
h
(15
pulse
h
)
Max. limit value DHW* / 3 to 500
pulse
h
(15
pulse
h
)
Limiting factor / 0.1 to 10.0 (1.0)
11 Flow rate limitation
in Rk1 with 0/4 to
20 mA at input
WMZ (with 50
Ω
in
parallel to input
WMZ terminal
03/13)
0 Not in Anl
10.0;
not in
systems
with
SF2/RF2
CO5 -> F11 - 1 only with CO5 -> F10 - 0
Input “WMZ/Bed“ (terminal 03/13)
Function block parameters:
Lower measuring range value 0 or 4 mA
Upper meas. range value 20 mA / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Max. limit value/ 0.01 to 650
m
h
3
(1.5
m
h
3
)
Max. limit value heating* / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Max. limit value DHW* / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Limiting factor / 0.1 to 10.0 (1.0)
12 Creep feed rate
limitation
0 Not in Anl
1.9
CO5 -> F12 - 1: Creep feed rate limitation,
input terminal 04/12
Function block parameter:
bE / 1, 0 (1)
13 Capacity limitation
based on a
connected flow rate
signal in Rk1
0 Not in Anl
1.9, 10.0;
not in
systems
with
SF2/RF2
CO5 -> F13 - 1 only with CO5 -> F11 - 1
Connection of primary flow sensor at input FG2
Function block parameters:
Max. limit value / 0.1 to 6500 kW (1.5 kW)
Max. limit value heating* / 0.1 to 6500 kW (1.5 kW))
Max. limit value DHW* / 0.1 to 6500 kW (1.5 kW)
Limiting factor / 0.1 to 10.0 (0.1)
16 Return flow
temperature
limitation with P
algorithm
0 All CO5 -> F16 - 1: Return flow temperature limitation with
P-action only
19 Temperature
monitoring
0 All CO5 -> F19 - 1: Temperature monitoring active
20 Sensor calibration 1 All CO5 -> F20 - 1: Adjusting all sensor calibration values
CO5 -> F20 - 0: Deleting all sensor calibration values
21 Locking manual
level
0 All CO5 -> F21 - 1: In switch position , automatic mode is
applied
110 EB 5575 EN
Appendix
