Samson TROVIS 5575 - Page 112

CO7: Device bus (all systems; F02, F03, … only with CO7 -> F01 -1)
Settings in CO7 level do not apply for TROVIS 5575-002x version.
F Function WE Anl
Comment
Function block parameters/Range of values (default setting)
01 Device bus 0 All CO7 -> F01 - 1: Device bus active
Function block parameter:
Device bus address /Auto*, 1 to 32 (32)
*Auto = controller automatically searches for free device bus
address in the system
02 Clock
synchronization
0 All CO7 -> F02 - 1: Controller sends its system time to all units
connected to the device bus every 24 hours
03 TROVIS 5570
Room Panel in Rk1
0 1.0–1.3,
2.x, 4.x,
10.0,
11.x
CO7 -> F03 - 1: Communication with TROVIS 5570 active
for RK1; CO1 -> F01 - 1 is set automatically
Function block parameter:
Device bus address / Auto*, 1 to 32 (32)
*Auto = controller automatically searches for a room panel
for which detection mode has been activated
04 TROVIS 5570
Room Panel in Rk2
0 3.x, 4.x,
10.0
CO2 -> F01 - 1: Communication with TROVIS 5570 active
for Rk2; CO2 -> F01 - 1 is set automatically
Function block parameter:
Device bus address / Auto*, 1 to 32 (32)
*Auto = controller automatically searches for a room panel
for which detection mode has been activated
05 Reserved
06 Send value AF1 0 Not Anl
1.9
Function block parameter:
Register no. / 1 to 4 (1)
07 Receive value AF1 0 Not Anl
1.9
Function block parameter:
Register no. / 1 to 4 (1)
08 Reserved
09 Receive value AF2 0 Not Anl
1.9
Function block parameter:
Register no. / 1 to 4 (2)
10 Send flow set point
Rk1
0 All CO7 -> F10 - 1: In systems Anl 1.5, 1.6, 2.x, 3.0, 4.0, 4.1,
the storage tank charging set point is sent during DHW
heating
Function block parameter:
Register no./5to64(5)
11 Send flow set point
Rk2
0 All Function block parameter:
Register no./5to64(5)
112 EB 5575 EN
Appendix
