System Anl 3.2 (TROVIS 5575-001x version only)
Default setting
CO1 -> F02 - 1 (with AF1)
CO1 -> F03 - 1 (with RüF1)
CO2 -> F01 - 0 (without RF2)
CO2 -> F03 - 0 (without RüF2)
CO4 -> F01 - 1 (with SF1)
CO4 -> F02 - 1 (with SF2)
40 EB 5575 EN
Systems
BE
BA
AE
RK
AF1
RüF1
VF1
UP2
RK2RK1
RF2
VF2
RüF2 UP1
SLP
WW
KW
SF1
ZP
SF2
