Samson TROVIS 5575 - Page 43

System Anl 4.1 (all versions of TROVIS 5575-00xx)
* Note
The circulation pump ZP can only be controlled with the
TROVIS 5575-001x version.
Default setting
CO1 -> F01 - 0 (without RF1)
CO1 -> F02 - 1 (with AF1)
CO1 -> F03 - 1 (with RüF1)
CO2 -> F01 - 0 (without RF2)
CO2 -> F03 - 0 (without RüF2)
CO4 -> F01 - 1 (with SF1)
CO4 -> F02 - 0 (without SF2)
EB 5575 EN 43
Systems
BE
BA
AE
RK
AF1
RüF1
VF1
UP2
RK2RK1
RF2
VF2
RüF2
RF1
UP1
WW
KW
SLP ZP* SF1
