System Anl 11.9 (all versions of TROVIS 5575-00xx)
Default setting
CO1 -> F01 - 0 (without RF1)
CO1 -> F02 - 1 (with AF1)
CO1 -> F03 - 1 (with RüF1)
CO4 -> F01 - 0 (without SF1)
CO4 -> F03 - 0 (without RüF2)
CO4 -> F04 - 0 (without water flowmeter connected to terminals 03/13)
EB 5575 EN 49
Systems
