17-10 EB 6493 EN
Annex A (conguration guide)
 …  ……………  or  ……………………………………  ………………… ……………………………  or  ……………………  and , followed by
Menu Function -CO-
Setting
options
1)
Description of functions Parameter level -PA-
Parameter
selection Parameter name Value range
1)
Output functions
OUT SAFE
Activate constant
output value
oFF SA.VA
bi1 SA.VA
OFF
By binary input BI1 SAFE/SA.VA
Y1K1 Constant output value [–10.0…0.0…+110.0%]
MA.AU
Manual/automatic
switchover
oFF CH.MA
bi1 CH.MA
OFF
By binary input BI1
noPA MA.AU/CH.MA No
parameters
Y.LIM
Control signal limita-
tion YPID
on LI.YP ON Y.LIM/LI.YP
Y
Y
Min. manipulated variable
Max. manipulated variable
[–10.0…0.0…+110.0%]
[–10.0…+100.0…+110.0%]
RAMP
Manipulated variable
ramp/limitation of
rate of change for
manipulated variable
oFF RA.YP OFF
F01 RA.YP Ramp increasing,
start with –10% by BI1
RAMP/RA.YP
TSRA
Y1RA
Running time
Initial value
[1…9999s]
[–10.0…0.0…+110.0%]
F02 RA.YP Ramp increasing/decreasing,
start with Y1RA by BI1
F03 RA.YP Limitation when manipulated
variable decreases and increases
F04 RA.YP
F05 RA.YP
Limitation when manipulated variable
increases
Limitation when manipulated variable
decreases
BLOC
Locking manipulated
variable YPID
oFF BL.YP
on BL.YP
OFF
By binary input BI1
noPA BLOC/BL.YP
No parameter
FUNC
Function generation
manipulated
variable
oFF FU.YP OFF K1.X Input value 1 [–10.0…0.0…+110.0%]
on FU.YP ON FUNC/FU.YP K1.Y
…
K7.X
K7.Y
Output value 1
…
Input value 7
Output value 7
[–10.0…0.0…+110.0%]
…
[–10.0…0.0…+110.0%]
[–10.0…0.0…+110.0%]
Y.VA
Signal range for an-
alog output Y
oFF Y
0–20 mA
4–20 mA
0–10 V
2–10 V
OFF
0 to 20 mA
4 to 20 mA
0 to 10 V
2 to 10 V
Fno PA Y.VA/Y
no PA Y.VA/mA
no PA Y.VA/mA
no PA Y.VA/V
no PA Y.VA/V
No parameter
1)
Default setting is in bold print.
