Sanding STS-752RC - Page 38

37
The height of station is calculated.
Press PAGE to display the Page 2/2.
Press FACE, and focus the same point in
Face Ⅱ, then press All to measure the
same point in Face Ⅱ.
【Ht.Tran.Result】 1/2 ▼
StnPt
:
OCC1
H0
:
8.250 m
Corr.
:
0.000 m
NoPts
:
1
AddPt
FACE
BACK
OK
【Ht.Tran.Result】 2/2 ▲
StnPt
:
OCC1
X0/N0
:
100.000 m
Y0/E0
:
100.000 m
H0
:
8.250 m
NoPts
:
1
St.Dev
:
0.000 m
AddPt
FACE
BACK
OK
After measurement, press AddPt.
Repeat the procedures above to measure
next known point (or new added point) in
both Face Ⅰ and Face Ⅱ.
You can measure maximum 5 points.
【Height Transfer】
Select Target Meas!
PtID
:
------
R.HT
:
1.500 M
H/Z
:
----.--- m
Ⅰ
:
----.--- m
Mem.
EHN
INS.HT
VIEW
│←
You can measure maximum 5 points.
【Ht.Tran.Result】 1/2 ▼
StnPt
:
OCC1
H0
:
8.252 m
Corr.
:
0.002 m
NoPts
:
5
AddPt
FACE
BACK
OK
Press OK to confirm the height transfer
result.
BACK: Back to the height transfer result.
OLD: Maintain the original station height.
AVE.: Calculate the average value of the
original and new heights, and consider it
as the station height.
NEW: Consider the new height as the
station height.
【H0 Exist】
StnPt
:
OCC1
Old H0
:
8.000 m
New H0
:
8.252 m
△H0
:
0.252 m
BACK
OLD
AVE.
NEW
