58
2) Easting and northing is determined by the method of least squares, including
standard deviation and improvements for HZ-direction and horizontal distances.
3) The final height is computed from averaged height differences based on the
original measurement.
4) The HZ-circle orientation is computed by the original average face I and face II
measurements and the final computed plan position.
STEPS
DISPLAY
Press F3 to enter to Free Station function
in the menu of Programs.
【Free Station】
[*]
F1
Setting job
(1)
F2
Setting limit
(2)
F4
Start
(4)
F1
F2
F4
Press F1 to set a job.
Select the job name, or create a new job
by press ADD.
After setting the job, press OK.
The screen returns to upper level.
【Setting Job】 5/8
Job
:
SANDING
Name
:
JOHN
Date
:
2011.01.01
Time
:
16:02:09
ADD
OK
Press F2 to set the limit.
Input all the deviation limits as shown on
the right.
Press SET. to confirm.
The screen returns to upper level.
【Setting Limit】
Input Limit!
Status
:
ON
St.dev.X/N
:
0.010 m
St.dev.Y/E
:
0.010 m
St.dev.H/Z
:
0.010 m
St.dev.Ang
:
0°00′00″
SET.
Press F4 to start Free Station.
Input the station point and the instrument
height. Press OK to confirm.
【Free-Station STN PT】
StnPt
:
OCC1
INS.Ht
:
2.000 m
OK
