Input the target point ID and reflector
height, and press OK to confirm.
You can also call up a point by SEARCH
or LIST.
【Free-Station TGT PT】
PtID
:
2
R.Ht
:
1.500 m
SEARCH
LIST
OK
↓
Collimate the Target Point 2 and press All
to trigger the measurement.
After one measurement, press NextPt to
process to the measurement of the next
point.
【Free-Station Measure】
PtID
:
2
R.HT
:
1.500 m
HZ
:
38°26′06″
V
:
20°00′05″
:
----.--- m
Ⅰ
RESULT
NextPt
All
↓
When at least 2 points and 1 side are
measured, the coordinates of station
point can be calculated and displayed.
【Limit Check】
St.DevX0
:
0.010 m
St.DevY0
:
1.010 m
St.DevH0
:
0.010 m
StDevAng
:
0°00′00″
Continue?
BACK
OK
Press OK to view the free station result.
【Free-Station Result】
StnPt
:
OCC1
INS.HT
:
2.000 m
X0/Y0
:
10.000 m
Y0/E0
:
10.001 m
H0
:
10.001 m
BACK
RESID
StnDev
OK
Press RESID to view the residuals.
【Free-ST Residuals】 1/5
PtID
:
2
△Hz
:
0°00′01″
△
:
0.001 m
△
:
0.002 m
BACK
OK
