Sanding STS-752RC - Intersections

63
5.7.1.2 Inverse
The known data:
P1: The first known point
P2: The second known point
The unknown data:
α:Direction from P1 to P2
d1: Slope distance between P1 and P2 .
d2: Horizontal distance between P1 and P2
d3: Height distance between P1 and P2
STEPS
DISPLAY
Press F2 to start Inverse.
Input 2 known points, one as the point to
start and the other as the point to end.
Or you can call up the points from the
LIST.
【Inverse】
From
:
21
To
:
22
MEAS
CALC
SEARCH
↓
Press CALC to calculate the display the
result.
Press RECORD to save the result. Press
ESC to quit and start a new Inverse
calculation.
【Inverse Result】
Point1
:
21
Point2
:
21
AZ
:
90°00′00″
△
:
10.000 m
△
:
10.000 m
△
:
0.000 m
RECORD
