Sanding STS-752RC - “Stake Out” Subapplication

85
5.11.2.2 “Line & Offset” Subapplication
Here you can measure or select points from memory and you will see Line and
Offset referring to the arc.
Press MEAS to start Line & Offset
Measure.
【Reference Arc-Window】
Center
:
------
StartPt
:
10
End Pt
:
11
Radius
:
12.650 m
NewArc
MEAS
STAKE
Input the PtID and its prism height and
press All to start measurement. You can
also call up the point by SEARCH or
LIST, or input the coordinates by pressing
ENH if the PtID does not exist.
【Line&Offset Measure】
PtID
:
21
R.HT
:
2.000 m
Line
:
----.--- m
Offset
:
----.--- m
△
:
----.--- m
Ⅰ
Mem.
All
DIST
RECORD
↓
Input the radius and press OK.
【Reference Arc】
Input Arc Radius!
Radius
:
----.--- m
OK
Then a reference arc is defined.
Now you are to decide whether to
measure or to stake out.
【Reference Arc-Window】
Center
:
------
StartPt
:
10
End Pt
:
11
Radius
:
12.650 m
NewArc
MEAS
STAKE
