84
Set the PtID of the center point of the arc
and its prism height.
Input the PtID and its prism height and
press All to start measurement. You can
also call up the point by SEARCH or
LIST, or input the coordinates by pressing
ENH if the PtID does not exist.
【Define Ref. Arc】 1/3 ▼
Sight Meas CenterPt
Center
:
10
R.HT
:
1.000 m
:
----.--- m
Ⅰ
:
----.--- m
Mem.
All
SEARCH
LIST
↓
Set the PtID of the start point and its
prism height via the methods above.
【Define Ref. Arc】 1/3 ▼
Sight Meas CenterPt
Center
:
10
StartPt
:
11
R.HT
:
1.500 m
:
----.--- m
Ⅰ
:
----.--- m
Mem.
All
SEARCH
LIST
↓
Then a reference arc is defined.
Now you are to decide whether to
measure or to stake out.
【Reference Arc-Window】
Center
:
10
StartPt
:
11
End Pt
:
------
Radius
:
2.650 m
NewArc
MEAS
STAKE
b) CenterPt & EndPt & Radius
Press F2 to choose to define the
reference arc by StartPt & EndPt &
Radius.
【Define Ref. Arc Method】
F1
CenterPt & StartPt
F2
StartPt & EndPt &Radius
F1
F2
Set the PtID of the start point and its
prism height.
And set the PtID of the end point and its
prism height.
【Define Ref. Arc】 1/3 ▼
Sight Meas Start Pt!
StartPt
:
10
End Pt
:
11
R.HT
:
1.500 m
:
----.--- m
Ⅰ
:
----.--- m Mem.
All
SEARCH
LIST
↓
