Sanremo D8 - Dimensions

D8
Description
20
3.2.1 DIMENSIONS
Y
Z
X
DESCRIPTION U.o.M.
2
GROUPS
3
GROUPS
X Length mm 808 1036
Y Depth mm 555
Z Height mm 500
D
C
B
A
DESCRIPTION U.o.M.
2
GROUPS
3
GROUPS
A
Height from dispensing
spout to cup tray
STANDARD mm 90
TALL mm 144
B
Height from drip tray to
base
min mm 38
max mm 88
C Support depth mm 450,8
D Support dimension mm 407,5
Cup heating plate dimensions cm² 1814 2334
