MPM-210 Operation Manual
Code Error Message
0 No error
-100 Command error
-101 Invalid character
-103 Invalid separator
-104 Data type error
-108 Parameter not allowed
-109 Missing parameter
-111 Header Separator error
-113 Undened Header
-200 Execution error
-301 Is not Measurement Module
-302 Is not Responsed
-320 SPI CRC Err (SCB – MM Interface Error)
-321 SPI Rx CRC Err (SCB – MM Interface Error)
-322 SPI Rx Num Diff Err (SCB – MM Interface Error)
-350 Error Queue overow
■ 5-5-4 ERR?
All kinds of errors will be saved into message Que. By using a command ‘ERR?’, users
can pull out error information and read them all.
35. ZERO
Description
Before measuring optical power, run Zeroing to delete
electrical DC offset. Please be careful with incidence
light into Optic Port. When using the current meter
module, the MPM-213, please remove the BNC cable
from the MPM-213. This command action takes about 3
sec so please run other commands at least 3 sec later.
Syntax
ZERO
Example
ZERO
