67
Operating the Scale: FC
Device Parameters:
FCA Models
Password
You can enter a password to block
access to the operating menu and to
the functions for ID code input and
exact calibration weight input.
For details, see “Setting the Device
Parameters” in the chapter entitled
“Configuring the Scale”.
User ID
You can enter your own personal
password (20 characters max.)
Clock
ISO/GLP/GMP printouts in particular
must be generated with the date and
time stamp of the specific measure-
ment. This date and time stamp is
optional on other printouts.
For details, see “Setting the Device
Parameters” in the chapter entitled
“Configuring the Scale”.
Interface
Purpose
This item enables you to set the para-
meters for the following interfaces:
– Serial interface port
– External switch function
Serial communications port
You can set the serial communications
port to use for the following modes:
–
SBI
– XBPI
– YDPO1IS
– YDP02
– YDP03
– YDPO1IS-Label
– XBPI RS-485
– YDPO2IS
– YDPO2IS-Label
– YDPO4IS
– YDPO4IS-Label
Universal Remote Switch
You can connect an external universal
remote switch (foot switch) to one of
the two serial ports. Then you can
assign one of the following functions
to be performed when the switch is
activated:
–
Print key
– Tare key
– Cal key
– F1 function key
– CF key
– F2 function key
For further information on the pin
assignment chart, see “Pin Assignment
Charts” in the chapter entitled “Data
Output Functions”.
Display
You can configure the display for your
individual needs.
The contrast can be adjusted in 5
levels:
Contrast
Characters can be displayed in black
on white or vice versa:
Background
You can blank out either the bar
graph or the text line or both
Digit size
10mm + bar graph + text
display
13mm + bar graph
13mm + text display
13mm
You can blank out the display of
application symbols
Application symbols
