96
Step Key (or instruction) Display/Output
... or enter the desired value 1 0 . 6 0
9. Confirm the new value
Comp. soft key
Follow-on filling amount for
first component is displayed
10. Follow-on filling of 1st component Weigh the first component
up to 0
and store Comp.1 soft key
The true net value is displayed
for 2 seconds
11. Weigh in further components, Repeat steps 4 and 5
if called for in the formulation as needed
12. Toggle to the additive mode,
UAdd. soft key
if required
13. Add further components, Add components to container
as required ...
(here, e.g., up to the total weight
of the formulation:1,000 g)
Comp1 + 25.08 g
Comp2 + 10.73 g
R.div.+ 1.01226
RCom1 + 25.39 g
Comp1 + 25.08 g
Comp2 + 10.73 g
R.div.+ 1.01226
RECALC.: R.div.= 1.01226
RECALC.: Actual Net
RECALC.: Store
RECALC.: Store
Recalc
Recalc
s2
s2
