16 Operating Instructions YDP30 | YDP30-NET
Cleaning and Maintenance
7 Cleaning and Maintenance
7.1 Cleaning Device Surfaces
Procedure
t Switch off the device.
t Disconnect the power supply cable from the power supply
at the installation site.
t NOTICE Corrosion or damage to the device due to unsuit-
able cleaning agents!
t Do not use corrosive, chloride-containing or aggressive
cleaning agents.
t Do not use cleaning agents that contain abrasive
ingredients, e.g. scouring agents, steel wool.
t Do not use solvent-based cleaning agents.
t Make sure that cleaning materials, such as cloths, are
only slightly damp. Do not use wet cleaning cloths.
t Wipe the housing with a slightly damp cloth. Use a mild
soapy solution or a suitable cleaning agent for more severe
contaminations.
7.2 Maintenance Schedule
Interval Component Action Chapter,
page
Before media are inserted Print head Remove the ink ribbon. 7.3, 16
Clean the print head. 7.5.1, 17
Print roller Remove the media. 7.4, 17
Clean the print roller. 7.5.2, 17
After media are inserted Sensors Calibrate the sensors. 7.6, 18
Monthly Sensors Remove the media. 7.4, 17
Clean the sensors. 7.5.3, 17
As required Tear bar Remove the media. 7.4, 17
Clean the tear bar. 7.5.2, 17
Interior Remove the media. 7.4, 17
Clean the interior components. 7.6, 18
7.3 Removing the Ink Ribbon
Procedure
t Switch off the device.
t Open the top cover.
t Open the ink ribbon cover.
t Remove the ink ribbon’s paper winding spool from the
winding spool for the ink ribbon first on the left side, then
the right.
t Remove the ink ribbon’s supply spool from the intake for
the ink ribbon’s supply spool first on the left side, then the
right.
