Satec PM172EH series Reference Guide

37
Parameter Register Type R/W Range
The number of pre-event cycles
for the waveform log #1
0x860A UINT16 R/W 1 to 8
Nominal frequency 0x860B UINT16 R/W 50, 60 Hz
Maximum demand load current 0x860C UINT16 R/W 0 to 10000 A
(0 = CT primary current)
Reserved 0x8609 UINT16 R Read as 65535
The number of cycles in one
waveform series for the
waveform log #1
3
0x8610 UINT16 R 16 to 1280
Reserved 0x8611 UINT16 R Read as 65535
Nominal secondary voltage (L-L) 0x8612 UINT16 R/W 10 to 690 V
1
The wiring mode options are as follows:
3OP2 - 3-wire open delta using 2 CTs (2 element)
4LN3 - 4-wire WYE using 3 PTs (3 element), line-to-neutral voltage readings
3DIR2 - 3-wire direct connection using 2 CTs (2 element)
4LL3 - 4-wire WYE using 3 PTs (3 element), line-to-line voltage readings
3OP3 - 3-wire open delta using 3 CTs (2 1/2 element)
3LN3 - 4-wire WYE using 2 PTs (2 1/2 element), line-to-neutral voltage readings
3LL3 - 4-wire WYE using 2 PTs (2 1/2 element), line-to-line voltage readings
2LL1 - 2-wire line-to-line connection using 1 PT (1 element)
2
Synchronization of power demand interval can be made through a digital input.
3
The waveform recorder logs waveforms in series of records. A compound waveform can have as more as 1280 cycles
recorded in 80 consequent records, each record comprising 16 waveform cycles sampled at a rate of 32 samples per cycle.
5.4 User Selectable Options Setup
Table 5-9 User Selectable Options Registers
Parameter Register Type R/W Range
Power calculation mode 0x8700 UINT16 R/W 0 = using reactive power
1 = using non-active power
Energy roll value
1
0x8701 UINT16 R/W
0 = 1×10
4
kWh
1 = 1×10
5
kWh
2 = 1×10
6
kWh
3 = 1×10
7
kWh
4 = 1×10
8
kWh
5 = 1×10
9
kWh
Phase energy calculation mode 0x8702 UINT16 R/W 0 = disable, 1 = enable
Analog output option 0x8703 UINT16 R/W 0 = none
1 = 0-20 mA
2 = 4-20 mA
3 = 0-1 mA
4 = ±1 mA
Analog expander output
2
0x8704 UINT16 R/W 0 = none
1 = 0-20 mA
2 = 4-20 mA
3 = 0-1 mA
4 = ±1 mA
Reserved 0x8705-
0x8709
UINT16 R/W Read as 65535
Harmonic power/energy
calculation mode
0x870A UINT16 R/W 0 = disable, 1 = enable
1
For short energy readings (see Table 4-1), the maximum roll value will be 1×10
8
for positive readings and 1×10
7
for negative
readings.
2
Do not enable the analog expander output if the analog expander is not connected to the instrument, otherwise the
computer communications will become garbled.
