Satec PM172EH series Reference Guide

43
Action ID
Increment counter #3 0x4002
Increment counter #4 0x4003
Clear counter #1 0x4200
Clear counter #2 0x4201
Clear counter #3 0x4202
Clear counter #4 0x4203
Clear all counters 0x6400
Reset total energy 0x6000
Reset all total maximum demands 0x6100
Reset power maximum demands 0x6101
Reset volt/ampere maximum demands 0x6102
Reset TOU energy 0x6200
Reset TOU maximum demands 0x6300
Clear Min/Max registers 0x6500
Event log
2
0x7002
Data log #1 0x7100
Data log #2 0x7101
Data log #3 0x7102
Data log #4 0x7103
Data log #5 0x7104
Data log #6 0x7105
Data log #7 0x7106
Data log #8 0x7107
Waveform log #1 0x7200
Waveform log #2 0x7300
1
Operate/release actions via relays are automatically recorded to the event log whenever an electrical quantity, status input,
or phase reversal trigger is used.
2
Either setpoint transition (both operate and release) is recorded to the event log.
5.7 Relay Operation Control Registers
These registers allow you to manually override setpoint relay operations. Either relay may be manually
forced operated or released using commands sent via communications.
NOTES
1. A relay allocated as a pulsing relay may not be manually operated or released. When a relay is allocated for pulsing, it
automatically reverts to normal operation.
2. A relay is energized when forced operated, and is de-energized when forced released.
Table 5-15 Relay Operation Control Registers
Parameter Register Type R/W Range
Relay #1 control status 0x8400
UINT16
R/W see Table 5-16
Relay #2 control status 0x8401
UINT16
R/W see Table 5-16
Table 5-16 Relay Operation Status
Operation status ID
Normal operation 0
Force operate 1
Force release 2
5.8 Instrument Options Registers
Table 5-17 Instrument Options Registers
Parameter Register Type Direction Range
Options 1 register 0x7F00
UINT16
R see Table 5-18
Options 2 register 0x7F01
UINT16
R see Table 5-18
