5.15 Data Log Registers
These registers allow you to circularly read consequent records from the event log file. Each data log file is
accessed via a separate register window. Reading from either register window always returns the next logged
record from the corresponding data log. All registers within one window must be read at once using a single
request. After reading a log window, the partition queue pointer is shifted forward until the end of the log file. After
the last record has been read, the file pointer is automatically restored to the beginning of the log file so that the
next read request will return the first (oldest) record. To point to an arbitrary record, use the data log partition
status/control registers (see Section 5.13).
Table 5-33 Data Log Window Locations
Data log Window registers
Data log #1 0xC000-0xC017
Data log #2 0xC018-0xC02F
Data log #3 0xC030-0xC047
Data log #4 0xC048-0xC05F
Data log #5 0xC060-0xC077
Data log #6 0xC078-0xC08F
Data log #7 0xC090-0xC0A7
Data log #8 0xC0A8-0xC0BF
Reserved 0xC0C0-0xC17F
TOU Monthly Profile Log. Energy Reg. #1 0xC180-0xC197
TOU Monthly Profile Log. Energy Reg. #2 0xC198-0xC1AF
TOU Monthly Profile Log. Energy Reg. #3 0xC1B0-0xC1C7
TOU Monthly Profile Log. Energy Reg. #4 0xC1C8-0xC1DF
TOU Monthly Profile Log. Energy Reg. #5 0xC1E0-0xC1F7
TOU Monthly Profile Log. Energy Reg. #6 0xC1F8-0xC20F
TOU Monthly Profile Log. Energy Reg. #7 0xC210-0xC227
TOU Monthly Profile Log. Energy Reg. #8 0xC228-0xC23F
Reserved 0xC240-0xC2FF
TOU Monthly Profile Log. Max. Demand Reg. #1 0xC300-0xC317
TOU Monthly Profile Log. Max. Demand Reg. #2 0xC318-0xC32F
TOU Monthly Profile Log. Max. Demand Reg. #3 0xC330-0xC347
Reserved 0xC348-0xC47F
TOU Daily Profile Log. Energy Reg. #1 0xC480-0xC497
TOU Daily Profile Log. Energy Reg. #2 0xC498-0xC4AF
TOU Daily Profile Log. Energy Reg. #3 0xC4B0-0xC4C7
TOU Daily Profile Log. Energy Reg. #4 0xC4C8-0xC4DF
TOU Daily Profile Log. Energy Reg. #5 0xC4E0-0xC4F7
TOU Daily Profile Log. Energy Reg. #6 0xC4F8-0xC50F
TOU Daily Profile Log. Energy Reg. #7 0xC510-0xC527
TOU Daily Profile Log. Energy Reg. #8 0xC528-0xC53F
Reserved 0xC540-0xC5FF
TOU Daily Profile Log. Max. Demand Reg. #1 0xC600-0xC617
TOU Daily Profile Log. Max. Demand Reg. #2 0xC618-0xC62F
TOU Daily Profile Log. Max. Demand Reg. #3 0xC630-0xC647
Reserved 0xC648-0xC77F
If data log partition #7 is configured as a TOU monthly profile partition, registers 0xC090-0xC0A7 are mapped to
registers 0xC180-0xC197 for the first TOU monthly profile sub-partition allocated for TOU energy register #1, or if
this register is not configured, for the following first available TOU register.
If data log partition #8 is configured as a TOU daily profile partition, registers 0xC0A8-0xC0BF are mapped to
registers 0xC480-0xC497 for the first TOU daily profile sub-partition allocated for TOU energy register #1, or if this
register is not configured, for the following first available TOU register.
