Action Register Type R/W Range
Restore waveform log #2 read pointer 0xA00E UINT16 W 0
5.12 Memory Allocation Status Registers
Table 5-24 Log Memory Status Registers
Parameter Register Type R/W Range
Total memory size, Bytes 0xA0F0 UINT32 R 0 to 524288
Free memory size, Bytes 0xA0F1 UINT32 R 0 to 524288
Memory partitions map 0xA0F2 UINT32 R See Table 5-25
Monthly profile log partition map 0xA0F3 UINT32 R See Table 5-25
Daily profile log partition map 0xA0F4 UINT32 R See Table 5-25
Table 5-25 Log Partitions Allocation Map
Memory Partition/Sub-partition Bit
Event log 0
Data log #1 1
Data log #2 2
Data log #3 3
Data log #4 4
Data log #5 5
Data log #6 6
Data log #7 7
Data log #8 8
Reserved 9-16
Waveform log #1 17
Waveform log #2 18
Reserved 19-31
TOU Monthly Profile Log. Energy Reg. #1 0
TOU Monthly Profile Log. Energy Reg. #2 1
TOU Monthly Profile Log. Energy Reg. #3 2
TOU Monthly Profile Log. Energy Reg. #4 3
TOU Monthly Profile Log. Energy Reg. #5 4
TOU Monthly Profile Log. Energy Reg. #6 5
TOU Monthly Profile Log. Energy Reg. #7 6
TOU Monthly Profile Log. Energy Reg. #8 7
Reserved 8 - 15
TOU Monthly Profile Log. Max. Demand Reg. #1 16
TOU Monthly Profile Log. Max. Demand Reg. #2 17
TOU Monthly Profile Log. Max. Demand Reg. #3 18
Reserved 19-31
TOU Daily Profile Log. Energy Reg. #1 0
TOU Daily Profile Log. Energy Reg. #2 1
TOU Daily Profile Log. Energy Reg. #3 2
TOU Daily Profile Log. Energy Reg. #4 3
TOU Daily Profile Log. Energy Reg. #5 4
TOU Daily Profile Log. Energy Reg. #6 5
TOU Daily Profile Log. Energy Reg. #7 6
TOU Daily Profile Log. Energy Reg. #8 7
TOU Daily Profile Log. Energy Reg. #9 8 - 15
TOU Daily Profile Log. Max. Demand Reg. #1 16
TOU Daily Profile Log. Max. Demand Reg. #2 17
TOU Daily Profile Log. Max. Demand Reg. #3 18
Reserved 19-31
Bit meaning: 0 = a partition is not allocated; 1 = a partition is allocated
