NOTES
1. All digital inputs that were not allocated as pulse inputs will be automatically configured as status inputs.
2. A digital input allocated for the external demand synchronization pulse or time synchronization pulse will be automatically
configured as a pulse input.
Table 5-40 Digital Inputs Allocation Mask
Bit number Description
0 Digital input # 1 allocation status
1 Digital input # 2 allocation status
2-15 Not used
Bit meaning: 0 = input not allocated, 1 = input allocated to the group
5.19 Time Zone Information Registers
Table 5-41 Time Zone Registers
Parameter Register Type R/W Range
Daylight savings time (DST) option 0x8C00 UINT16 R/W 0 = disable DST (use standard time only),
1 = enable DST
DST start month 0x8C01 UINT16 R/W 1 - 12
DST start week of the month 0x8C02 UINT16 R/W 1 - 4 = 1st, 2nd, 3rd and 4th week,
5 = the last weekday in the month
DST start weekday 0x8C03 UINT16 R/W 1-7 (1= Sun, 7 = Sat)
DST end month 0x8C04 UINT16 R/W 1 - 12
DST end week of the month 0x8C05 UINT16 R/W 1 - 4 = 1st, 2nd, 3rd and 4th week,
5 = the last weekday in the month
DST end weekday 0x8C06 UINT16 R/W 1-7 (1= Sun, 7 = Sat)
5.20 Communications Password Register
Table 5-42 Password Register
Parameter Register Type R/W Range
Communications password 0xFF00 UINT16 R/W Write: 0 to 65535
Read:
0 = access permitted
65535 = authorization required
