Satec PM172EH series Reference Guide

39
5.6 Alarm/Event Setpoints
Table 5-11 Setpoint Setup Locations
Setpoint number Registers
Setpoint #1 8A00h-8A19h
Setpoint #2 8A1Ah-8A33h
Setpoint #3 8A34h-8A4Dh
Setpoint #4 8A4Eh-8A67h
Setpoint #5 8A68h-8A81h
Setpoint #6 8A82h-8A96h
Setpoint #7 8A9Ch-8AB5h
Setpoint #8 8AB6h-8ACFh
Setpoint #9 8AD0h-8AE9h
Setpoint #10 8AEAh-8B03h
Setpoint #11 8B04h-8B1Dh
Setpoint #12 8B1Eh-8B37h
Setpoint #13 8B38h-8B51h
Setpoint #14 8B52h-8B6Bh
Setpoint #15 8B6Ch-8B85h
Setpoint #16 8B86h-8B9Fh
Table 5-12 Setpoint Setup Registers
Parameter Offset Type R/W Range
Logical operator 1 +0
UINT16
R/W 0 = OR
Trigger ID 1 +1 UINT16 R/W see Table 5-13
Relational operator 1 +2 UINT16 R/W 0 (N/A)
Operate limit 1 +3 INT32 R/W see Table 5-13
Release limit 1 +4 INT32 R/W see Table 5-13
Logical operator 2 +5
UINT16
R/W 0 = OR, 1 = AND
Trigger ID 2 +6 UINT16 R/W see Table 5-13
Relational operator 2 +7 UINT16 R/W 0 (N/A)
Operate limit 2 +8 INT32 R/W see Table 5-13
Release limit 2 +9 INT32 R/W see Table 5-13
Logical operator 3 +10
UINT16
R/W 0 = OR, 1 = AND
Trigger ID 3 +11 UINT16 R/W see Table 5-13
Relational operator 3 +12 UINT16 R/W 0 (N/A)
Operate limit 3 +13 INT32 R/W see Table 5-13
Release limit 3 +14 INT32 R/W see Table 5-13
Logical operator 4 +15
UINT16
R/W 0 = OR, 1 = AND
Trigger ID 4 +16 UINT16 R/W see Table 5-13
Relational operator 4 +17 UINT16 R/W 0 (N/A)
Operate limit 4 +18 INT32 R/W see Table 5-13
Release limit 4 +19 INT32 R/W see Table 5-13
Action 1 +20
UINT16
R/W see Table 5-14
Action 2 +21 UINT16 R/W see Table 5-14
Action 3 +22 UINT16 R/W see Table 5-14
Action 4 +23 UINT16 R/W see Table 5-14
Operate delay +24
UINT16
R/W
0-9999 (×0.1 sec)
Release delay +25 UINT16 R/W
0-9999 (×0.1 sec)
Reserved +26, 27 UINT16 R 0
NOTES
1. The setpoint is disabled when the first trigger parameter ID is set to NONE. To disable the setpoint, write zero into this
register.
2. When writing the setpoint registers (except the event when the setpoint is to be disabled), it is recommended to write all
the setpoint registers using a single request, or to disable the setpoint before writing into separate registers. Each written
