value is checked for compatibility with the other setpoint parameters; if the new value does not conform to these, the
request will be rejected.
3. Operate and release limits for the trigger parameters and their ranges are indicated in Table 5-13. Limits indicated as N/A
are read as zeros. When writing, they can be omitted or should be written as zeros.
4. When a setpoint action is directed to a relay allocated to output energy pulses, an attempt to re-allocate it for a setpoint
will result in a negative response.
Table 5-13 Setpoint Triggers
Trigger parameter Trigger ID Unit
2
Range
1
None 0000h N/A
Internal events
Voltage disturbance
6
0x0100 % 1 to 100
Event flags
Event flag #1 ON 0x0300 N/A
Event flag #2 ON 0x0301 N/A
Event flag #3 ON 0x0302 N/A
Event flag #4 ON 0x0303 N/A
Event flag #5 ON 0x0304 N/A
Event flag #6 ON 0x0305 N/A
Event flag #7 ON 0x0306 N/A
Event flag #8 ON 0x0307 N/A
Event flag #1 OFF 0x8300 N/A
Event flag #2 OFF 0x8301 N/A
Event flag #3 OFF 0x8302 N/A
Event flag #4 OFF 0x8303 N/A
Event flag #5 OFF 0x8304 N/A
Event flag #6 OFF 0x8305 N/A
Event flag #7 OFF 0x8306 N/A
Event flag #8 OFF 0x8307 N/A
Internal events
kWh import pulse 0x0400 N/A
kWh export pulse 0x0401 N/A
kvarh import pulse 0x0403 N/A
kvarh export pulse 0x0404 N/A
kvarh total pulse 0x0405 N/A
kVAh total pulse 0x0406 N/A
Start new demand interval 0x0407 N/A
Start new tariff interval 0x0408 N/A
Start new volt/ampere demand interval 0x0409 N/A
Start new sliding window demand interval 0x040A N/A
Timers
Timer #1 0x0500 N/A
Timer #2 0x0501 N/A
Status inputs
Status input #1 ON 0x0600 N/A
Status input #2 ON 0x0601 N/A
Status input #1 OFF 0x8600 N/A
Status input #2 OFF 0x8601 N/A
Pulse inputs
Pulse input #1 0x0700 N/A
Pulse input #2 0x0701 N/A
Relay status
Relay #1 ON 0x0800 0 to 999999
Relay #2 ON 0x0801 0 to 999999
Relay #1 OFF 0x8800 0 to 999999
Relay #2 OFF 0x8801 0 to 999999
Phase reversal
Positive phase rotation reversal e 0x8901 N/A
Negative phase rotation reversal e 0x8902 N/A
Pulse counters
High pulse counter #1 0x0A00 0 to 999999
High pulse counter #2 0x0A01 0 to 999999
High pulse counter #3 0x0A02 0 to 999999
High pulse counter #4 0x0A03 0 to 999999
