Satec PM172EH series Reference Guide

47
5.13 Memory Partition Status/Control Registers
Table 5-26 Memory Partition Status/Control Register Locations
Memory Partition Registers
Event log 0xA100-0xA107
Data log #1 0xA108-0xA10F
Data log #2 0xA110-0xA117
Data log #3 0xA118-0xA11F
Data log #4 0xA120-0xA127
Data log #5 0xA128-0xA12F
Data log #6 0xA130-0xA137
Data log #7 0xA138-0xA13F
Data log #8 0xA140-0xA147
Reserved 0xA148-0xA1FF
TOU Monthly Profile Log. Energy Reg. #1 0xA200-0xA207
TOU Monthly Profile Log. Energy Reg. #2 0xA208-0xA20F
TOU Monthly Profile Log. Energy Reg. #3 0xA210-0xA217
TOU Monthly Profile Log. Energy Reg. #4 0xA218-0xA21F
TOU Monthly Profile Log. Energy Reg. #5 0xA220-0xA227
TOU Monthly Profile Log. Energy Reg. #6 0xA228-0xA22F
TOU Monthly Profile Log. Energy Reg. #7 0xA230-0xA237
TOU Monthly Profile Log. Energy Reg. #8 0xA238-0xA23F
Reserved 0xA240-0xA187
Waveform log #1 0xA188-0xA18F
Waveform log #2 0xA190-0xA197
Reserved 0xA198-0xA27F
TOU Monthly Profile Log. Max. Demand Reg. #1 0xA280-0xA287
TOU Monthly Profile Log. Max. Demand Reg. #2 0xA288-0xA28F
TOU Monthly Profile Log. Max. Demand Reg. #3 0xA290-0xA297
Reserved 0xA298-0xA2FF
TOU Daily Profile Log. Energy Reg. #1 0xA300-0xA307
TOU Daily Profile Log. Energy Reg. #2 0xA308-0xA30F
TOU Daily Profile Log. Energy Reg. #3 0xA310-0xA317
TOU Daily Profile Log. Energy Reg. #4 0xA318-0xA31F
TOU Daily Profile Log. Energy Reg. #5 0xA320-0xA327
TOU Daily Profile Log. Energy Reg. #6 0xA328-0xA32F
TOU Daily Profile Log. Energy Reg. #7 0xA330-0xA337
TOU Daily Profile Log. Energy Reg. #8 0xA338-0xA33F
Reserved 0xA340-0xA37F
TOU Daily Profile Log. Max. Demand Reg. #1 0xA380-0xA387
TOU Daily Profile Log. Max. Demand Reg. #2 0xA388-0xA38F
TOU Daily Profile Log. Max. Demand Reg. #3 0xA390-0xA397
Reserved 0xA398-0xA3FF
If data log partition #7 is configured as a TOU monthly profile partition, registers 0xA138-0xA13F are mapped to
registers 0xA200-0xA207 for the first TOU monthly profile sub-partition allocated for TOU energy register #1, or if
this register is not configured, for the following first available TOU register.
If data log partition #8 is configured as a TOU daily profile partition, registers 0xA140-0xA147 are mapped to
registers 0xA300-0xA307 for the first TOU daily profile sub-partition allocated for TOU energy register #1, or if this
register is not configured, for the following first available TOU register.
