Satec PM172EH series Reference Guide

19
Table 4-31 Write Request
Message type (ASCII)
‘g’
Message body (hexadecimal)
Request/Response
Field Offset Length Parameter Range
1 0 2 Pulse output ID 0-1 (see Table 4-32)
2 2 2 Output parameter ID see Table 4-33
3 4 4 For energy pulsing =
number of unit-hours per pulse,
otherwise - set to 0
0-9999
Table 4-32 Pulse Outputs
Pulsing output ID Output allocation
0 Relay #1
1 Relay #2
Table 4-33 Pulsing Output Parameters
Pulsing parameter ID Identifier
None 0
kWh import 1
kWh export 2
kvarh import 4
kvarh export 5
kvarh total (absolute) 6
kVAh total 7
4.13 User Event Flags Control
Table 4-34 Write Request
Message type (ASCII)
‘i’
Message body (hexadecimal)
Request/Response
Field Offset Length Parameter Range
1 0 2 Event flag number 0-7 = flag #1-#8
2 2 2 Event flag preset status 0-1
4.14 Pulse Counters Setup
Table 4-35 Read Request
Message type (ASCII)
‘J’
Message body (hexadecimal)
Request
Field Offset Length Parameter Range
1 0 2 Pulse counter ID 0-3 (see Table 4-37)
Response
Field Offset Length Parameter Range
1 0 2 Pulse counter ID 0-3 (see Table 4-37)
2 2 2 Digital input ID 0-1 (see Table 4-38)
3 4 4 Scale factor - number of units per pulse 1-9999
