Satec PM172EH series Reference Guide

55
file, the file pointer rolls over to the beginning of the file and the first (oldest) record is returned with bit 1 in the
status indication register being set to 1.
5.17 Min/Max Log Registers
These registers allow you to read time-stamped Min/Max log records using direct read requests.
Table 5-38 Min/Max Log Registers
Parameter Register Type
Unit
2
Range
1
Minimum real-time values per phase
Min. Voltage L1/L12
6
0xB000 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB001 UINT32
Min. Voltage L2/L23
6
0xB002 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB003 UINT32
Min. Voltage L3/L31
6
0xB004 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB005 UINT32
Min. Current L1 0xB006 UINT32 0.01A 0 to Imax
Timestamp 0xB007 UINT32
Min. Current L2 0xB008 UINT32 0.01A 0 to Imax
Timestamp 0xB009 UINT32
Min. Current L3 0xB00A UINT32 0.01A 0 to Imax
Timestamp 0xB00B UINT32
Reserved
Min. Voltage THD L1/L12 0xB024 UINT32 0.1% 0 to 9999
Timestamp 0xB025 UINT32
Min. Voltage THD L2/L23 0xB026 UINT32 0.1% 0 to 9999
Timestamp 0xB027 UINT32
Min. Voltage THD L3/L31 0xB028 UINT32 0.1% 0 to 9999
Timestamp 0xB029 UINT32
Min. Current THD L1 0xB02A UINT32 0.1% 0 to 9999
Timestamp 0xB02B UINT32
Min. Current THD L2 0xB02C UINT32 0.1% 0 to 9999
Timestamp 0xB02D UINT32
Min. Current THD L3 0xB02E UINT32 0.1% 0 to 9999
Timestamp 0xB02F UINT32
Min. Current K-Factor L1 0xB030 UINT32 0.1 10 to 9999
Timestamp 0xB031 UINT32
Min. Current K-Factor L2 0xB032 UINT32 0.1 10 to 9999
Timestamp 0xB033 UINT32
Min. Current K-Factor L3 0xB034 UINT32 0.1 10 to 9999
Timestamp 0xB035 UINT32
Min. Current TDD L1 0xB036 UINT32 0.1% 0 to 1000
Timestamp 0xB037 UINT32
Min. Current TDD L2 0xB038 UINT32 0.1% 0 to 1000
Timestamp 0xB039 UINT32
Min. Current TDD L3 0xB03A UINT32 0.1% 0 to 1000
Timestamp 0xB03B UINT32
Minimum real-time total values
Min. Total kW 0xB080 INT32 0.001kW/1kW -Pmax to Pmax
Timestamp 0xB081 UINT32
Min. Total kvar 0xB082 INT32 0.001kvar/1kvar -Pmax to Pmax
Timestamp 0xB083 UINT32
Min. Total kVA 0xB084 UINT32 0.001kVA/1kVA 0 to Pmax
Timestamp 0xB085 UINT32
Total PF
3
0xB086 UINT32 0.001 0 to 1000
Timestamp 0xB087 UINT32
Minimum real-time auxiliary values
Reserved 0xB100-0xB101 0
Min. Neutral current 0xB102 UINT32 0.01A 0 to Imax
Timestamp 0xB103 UINT32
Min. Frequency 0xB104 UINT32 0.01Hz
0 to 10000
4
Timestamp 0xB105 UINT32
