Satec PM172EH series Reference Guide

30
5.2 Extended Data Registers
Table 5-7 Extended Data Table
Parameter Point
ID
Type R/W Unit
Range
1
None
None 0x0000 UINT16 R 0
Event flags
Event flags (bitmap) 0x0300 UINT16 R see Table 4-13
Status inputs
Status inputs (bitmap) 0x0600 UINT16 R see Table 4-14
Relays
Relay status (bitmap) 0x0800 UINT16 R see Table 4-12
Pulse counters
Pulse counter #1 0x0A00 UINT32 R/W 0 to 999999
Pulse counter #2 0x0A01 UINT32 R/W 0 to 999999
Pulse counter #3 0x0A02 UINT32 R/W 0 to 999999
Pulse counter #4 0x0A03 UINT32 R/W 0 to 999999
Real-time values per phase
Voltage L1/L12
6
0x0C00 UINT32 R 0.1V/1V 0 to Vmax
Voltage L2/L23
6
0x0C01 UINT32 R 0.1V/1V 0 to Vmax
Voltage L3/L31
6
0x0C02 UINT32 R 0.1V/1V 0 to Vmax
Current L1 0x0C03 UINT32 R 0.01A 0 to Imax
Current L2 0x0C04 UINT32 R 0.01A 0 to Imax
Current L3 0x0C05 UINT32 R 0.01A 0 to Imax
kW L1 0x0C06 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L2 0x0C07 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L3 0x0C08 INT32 R 0.001kW/1kW -Pmax to Pmax
kvar L1 0x0C09 INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L2 0x0C0A INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L3 0x0C0B INT32 R 0.001kvar/1kvar -Pmax to Pmax
kVA L1 0x0C0C UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L2 0x0C0D UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L3 0x0C0E UINT32 R 0.001kVA/1kVA 0 to Pmax
Power factor L1 0x0C0F INT16 R 0.001 -999 to 1000
Power factor L2 0x0C10 INT16 R 0.001 -999 to 1000
Power factor L3 0x0C11 INT16 R 0.001 -999 to 1000
Voltage THD L1/L12 0x0C12 UINT16 R 0.1% 0 to 9999
Voltage THD L2/L23 0x0C13 UINT16 R 0.1% 0 to 9999
Voltage THD L3 0x0C14 UINT16 R 0.1% 0 to 9999
Current THD L1 0x0C15 UINT16 R 0.1% 0 to 9999
Current THD L2 0x0C16 UINT16 R 0.1% 0 to 9999
Current THD L3 0x0C17 UINT16 R 0.1% 0 to 9999
K-Factor L1 0x0C18 UINT16 R 0.1 10 to 9999
K-Factor L2 0x0C19 UINT16 R 0.1 10 to 9999
K-Factor L3 0x0C1A UINT16 R 0.1 10 to 9999
Current TDD L1 0x0C1B UINT16 R 0.1% 0 to 1000
Current TDD L2 0x0C1C UINT16 R 0.1% 0 to 1000
Current TDD L3 0x0C1D UINT16 R 0.1% 0 to 1000
Voltage L12 0x0C1E UINT32 R 0.1V/1V 0 to Vmax
Voltage L23 0x0C1F UINT32 R 0.1V/1V 0 to Vmax
Voltage L31 0x0C20 UINT32 R 0.1V/1V 0 to Vmax
Real-time total values
Total kW 0x0F00 INT32 R 0.001kW/1kW -Pmax to Pmax
Total kvar 0x0F01 INT32 R 0.001kvar/1kvar -Pmax to Pmax
Total kVA 0x0F02 UINT32 R 0.001kVA/1kVA 0 to Pmax
Total PF 0x0F03 INT16 R 0.001 -999 to 1000
Real-time auxiliary values
Reserved 0x1000 UINT32 R 0
Neutral current 0x1001 UINT32 R 0.01A 0 to Imax
Frequency 0x1002 UINT16 R 0.01Hz 0 to 10000
4
Voltage unbalance 0x1003 UINT16 R 1% 0 to 300
Current unbalance 0x1004 UINT16 R 1% 0 to 300
