Satec PM172EH series Reference Guide

31
Parameter Point
ID
Type R/W Unit
Range
1
Average values per phase
Voltage L1/L12
6
0x1100 UINT32 R 0.1V/1V 0 to Vmax
Voltage L2/L23
6
0x1101 UINT32 R 0.1V/1V 0 to Vmax
Voltage L3/L31
6
0x1102 UINT32 R 0.1V/1V 0 to Vmax
Current L1 0x1103 UINT32 R 0.01A 0 to Imax
Current L2 0x1104 UINT32 R 0.01A 0 to Imax
Current L3 0x1105 UINT32 R 0.01A 0 to Imax
kW L1 0x1106 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L2 0x1107 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L3 0x1108 INT32 R 0.001kW/1kW -Pmax to Pmax
kvar L1 0x1109 INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L2 0x110A INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L3 0x110B INT32 R 0.001kvar/1kvar -Pmax to Pmax
kVA L1 0x110C UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L2 0x110D UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L3 0x110E UINT32 R 0.001kVA/1kVA 0 to Pmax
Power factor L1 0x110F INT16 R 0.001 -999 to 1000
Power factor L2 0x1110 INT16 R 0.001 -999 to 1000
Power factor L3 0x1111 INT16 R 0.001 -999 to 1000
Voltage THD L1/L12 0x1112 UINT16 R 0.1% 0 to 9999
Voltage THD L2/L23 0x1113 UINT16 R 0.1% 0 to 9999
Voltage THD L3 0x1114 UINT16 R 0.1% 0 to 9999
Current THD L1 0x1115 UINT16 R 0.1% 0 to 9999
Current THD L2 0x1116 UINT16 R 0.1% 0 to 9999
Current THD L3 0x1117 UINT16 R 0.1% 0 to 9999
K-Factor L1 0x1118 UINT16 R 0.1 10 to 9999
K-Factor L2 0x1119 UINT16 R 0.1 10 to 9999
K-Factor L3 0x111A UINT16 R 0.1 10 to 9999
Current TDD L1 0x111B UINT16 R 0.1% 0 to 1000
Current TDD L2 0x111C UINT16 R 0.1% 0 to 1000
Current TDD L3 0x111D UINT16 R 0.1% 0 to 1000
Voltage L12 0x111E UINT32 R 0.1V/1V 0 to Vmax
Voltage L23 0x111F UINT32 R 0.1V/1V 0 to Vmax
Voltage L31 0x1120 UINT32 R 0.1V/1V 0 to Vmax
Average total values
Total kW 0x1400 INT32 R 0.001kW/1kW -Pmax to Pmax
Total kvar 0x1401 INT32 R 0.001kvar/1kvar -Pmax to Pmax
Total kVA 0x1402 UINT32 R 0.001kVA/1kVA 0 to Pmax
Total PF 0x1403 INT16 R 0.001 -999 to 1000
Average auxiliary values
Reserved 0x1500 UINT32 R 0
Neutral current 0x1501 UINT32 R 0.01A 0 to Imax
Frequency 0x1502 UINT16 R 0.01Hz 0 to 10000
4
Voltage unbalance 0x1503 UINT16 R 1% 0 to 300
Current unbalance 0x1504 UINT16 R 1% 0 to 300
Present demands
Volt demand L1/L12
6
0x1600 UINT32 R 0.1V/1V 0 to Vmax
Volt demand L2/L23
6
0x1601 UINT32 R 0.1V/1V 0 to Vmax
Volt demand L3/L31
6
0x1602 UINT32 R 0.1V/1V 0 to Vmax
Ampere demand L1 0x1603 UINT32 R 0.01A 0 to Imax
Ampere demand L2 0x1604 UINT32 R 0.01A 0 to Imax
Ampere demand L3 0x1605 UINT32 R 0.01A 0 to Imax
Block kW import demand 0x1606 UINT32 R 0.001kW/1kW 0 to Pmax
Block kvar import demand 0x1607 UINT32 R 0.001kvar/1kvar 0 to Pmax
Block kVA demand 0x1608 UINT32 R 0.001kVA/1kVA 0 to Pmax
Sliding window kW import demand 0x1609 UINT32 R 0.001kW/1kW 0 to Pmax
Sliding window kvar import demand 0x160A UINT32 R 0.001kvar/1kvar 0 to Pmax
Sliding window kVA demand 0x160B UINT32 R 0.001kVA/1kVA 0 to Pmax
Reserved 0x160C UINT32 R 0
Reserved 0x160D UINT32 R 0
Reserved 0x160E UINT32 R 0
Accumulated kW import demand 0x160F UINT32 R 0.001kW/1kW 0 to Pmax
Accumulated kvar import demand 0x1610 UINT32 R 0.001kvar/1kvar 0 to Pmax
