32
Parameter Point
ID
Type R/W Unit
Range
1
Accumulated kVA demand 0x1611 UINT32 R 0.001kVA/1kVA 0 to Pmax
Predicted sliding window kW import
demand
0x1612 UINT32 R 0.001kW/1kW 0 to Pmax
Predicted sliding window kvar import
demand
0x1613 UINT32 R 0.001kvar/1kvar 0 to Pmax
Predicted sliding window kVA demand 0x1614 UINT32 R 0.001kVA/1kVA 0 to Pmax
PF (import) at maximum sliding window
kVA demand
0x1615 UINT16 R 0.001 0 to 1000
Block kW export demand 0x1616 UINT32 R 0.001kW/1kW 0 to Pmax
Block kvar export demand 0x1617 UINT32 R 0.001kvar/1kvar 0 to Pmax
Sliding window kW export demand 0x1618 UINT32 R 0.001kW/1kW 0 to Pmax
Sliding window kvar export demand 0x1619 UINT32 R 0.001kvar/1kvar 0 to Pmax
Accumulated kW export demand 0x161A UINT32 R 0.001kW/1kW 0 to Pmax
Accumulated kvar export demand 0x161B UINT32 R 0.001kvar/1kvar 0 to Pmax
Predicted sliding window kW export
demand
0x161C UINT32 R 0.001kW/1kW 0 to Pmax
Predicted sliding window kvar export
demand
0x161D UINT32 R 0.001kvar/1kvar 0 to Pmax
Total energies
kWh import 0x1700 UINT32 R kWh
0 to 10
9
-1
kWh export 0x1701 UINT32 R kWh
0 to 10
9
-1
Reserved 0x1702-
0x1703
UINT32 R 0
kvarh import 0x1704 UINT32 R kvarh
0 to 10
9
-1
kvarh export 0x1705 UINT32 R kvarh
0 to 10
9
-1
Reserved 0x1706-
0x1707
UINT32 R 0
kVAh total 0x1708 UINT32 R kVAh
0 to 10
9
-1
Reserved 0x1709-
0x170C
UINT32 R 0
Harmonic kWh import 0x170D UINT32 R kWh
0 to 10
9
-1
Harmonic kWh export 0x170E UINT32 R kWh
0 to 10
9
-1
Reserved 0x170F-
0x1710
UINT32 R 0
Harmonic kVAh 0x1711 UINT32 R kVAh
0 to 10
9
-1
Phase energies
kWh import L1
0x1800
UINT32 R kWh
0 to 10
9
-1
kWh import L2
0x1801
UINT32 R kWh
0 to 10
9
-1
kWh import L3
0x1802
UINT32 R kWh
0 to 10
9
-1
kvarh import (inductive) L1
0x1803
UINT32 R kvarh
0 to 10
9
-1
kvarh import (inductive) L2
0x1804
UINT32 R kvarh
0 to 10
9
-1
kvarh import (inductive) L3
0x1805
UINT32 R kvarh
0 to 10
9
-1
kVAh L1
0x1806
UINT32 R kVAh
0 to 10
9
-1
kVAh L2
0x1807
UINT32 R kVAh
0 to 10
9
-1
kVAh L3
0x1808
UINT32 R kVAh
0 to 10
9
-1
L1/L12 voltage harmonics
Harmonic H01 0x1900 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1901 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x193E UINT16 R 0.01% 0 to 10000
L2/L23 voltage harmonics
Harmonic H01 0x1A00 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1A01 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x1A3E UINT16 R 0.01% 0 to 10000
L3 voltage harmonics
Harmonic H01 0x1B00 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1B01 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x1B3E UINT16 R 0.01% 0 to 10000
