Satec PM172EH series Reference Guide

33
Parameter Point
ID
Type R/W Unit
Range
1
L1 current harmonics
Harmonic H01 0x1C00 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1C01 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x1C3E UINT16 R 0.01% 0 to 10000
L2 current harmonics
Harmonic H01 0x1D00 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1D01 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x1D3E UINT16 R 0.01% 0 to 10000
L3 current harmonics
Harmonic H01 0x1E00 UINT16 R 0.01% 0 to 10000
Harmonic H02 0x1E01 UINT16 R 0.01% 0 to 10000
... ...
Harmonic H40 0x1E3E UINT16 R 0.01% 0 to 10000
Fundamental's (H01) real-time values per phase
Voltage L1/L12 0x2900 UINT32 R 0.1V/1V 0 to Vmax
Voltage L2/L23 0x2901 UINT32 R 0.1V/1V 0 to Vmax
Voltage L3/L31 0x2902 UINT32 R 0.1V/1V 0 to Vmax
Current L1 0x2903 UINT32 R 0.01A 0 to Imax
Current L2 0x2904 UINT32 R 0.01A 0 to Imax
Current L3 0x2905 UINT32 R 0.01A 0 to Imax
kW L1 0x2906 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L2 0x2907 INT32 R 0.001kW/1kW -Pmax to Pmax
kW L3 0x2908 INT32 R 0.001kW/1kW -Pmax to Pmax
kvar L1 0x2909 INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L2 0x290A INT32 R 0.001kvar/1kvar -Pmax to Pmax
kvar L3 0x290B INT32 R 0.001kvar/1kvar -Pmax to Pmax
kVA L1 0x290C UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L2 0x290D UINT32 R 0.001kVA/1kVA 0 to Pmax
kVA L3 0x290E UINT32 R 0.001kVA/1kVA 0 to Pmax
Power factor L1 0x290F INT16 R 0.001 -999 to 1000
Power factor L2 0x2910 INT16 R 0.001 -999 to 1000
Power factor L3 0x2911 INT16 R 0.001 -999 to 1000
Harmonic real-time total values
Total fundamental kW 0x2A00 INT32 R 0.001kW/1kW -Pmax to Pmax
Total fundamental kvar 0x2A01 INT32 R 0.001kvar/1kvar -Pmax to Pmax
Total fundamental kVA 0x2A02 UINT32 R 0.001kVA/1kVA 0 to Pmax
Total fundamental PF 0x2A03 INT16 R 0.001 -999 to 1000
Total harmonic kW 0x2A04 INT32 R 0.001kW/1kW -Pmax to Pmax
Reserved 0x2A05 INT32 R 0
Total harmonic kVA 0x2A06 UINT32 R 0.001kVA/1kVA 0 to Pmax
Reserved 0x2A07 INT16 R 0
Minimum real-time values per phase (M)
Voltage L1/L12
6
0x2C00 UINT32 R 0.1V/1V 0 to Vmax
Voltage L2/L23
6
0x2C01 UINT32 R 0.1V/1V 0 to Vmax
Voltage L3/L31
6
0x2C02 UINT32 R 0.1V/1V 0 to Vmax
Current L1 0x2C03 UINT32 R 0.01A 0 to Imax
Current L2 0x2C04 UINT32 R 0.01A 0 to Imax
Current L3 0x2C05 UINT32 R 0.01A 0 to Imax
Reserved 0
Voltage THD L1/L12 0x2C12 UINT16 R 0.1% 0 to 9999
Voltage THD L2/L23 0x2C13 UINT16 R 0.1% 0 to 9999
Voltage THD L3/L31 0x2C14 UINT16 R 0.1% 0 to 9999
Current THD L1 0x2C15 UINT16 R 0.1% 0 to 9999
Current THD L2 0x2C16 UINT16 R 0.1% 0 to 9999
Current THD L3 0x2C17 UINT16 R 0.1% 0 to 9999
K-Factor L1 0x2C18 UINT16 R 0.1 10 to 9999
K-Factor L2 0x2C19 UINT16 R 0.1 10 to 9999
K-Factor L3 0x2C1A UINT16 R 0.1 10 to 9999
Current TDD L1 0x2C1B UINT16 R 0.1% 0 to 1000
Current TDD L2 0x2C1C UINT16 R 0.1% 0 to 1000
Current TDD L3 0x2C1D UINT16 R 0.1% 0 to 1000
