Satec PM172EH series Reference Guide

34
Parameter Point
ID
Type R/W Unit
Range
1
Minimum real-time total values (M)
Total kW 0x2D00 INT32 R 0.001kW/1kW -Pmax to Pmax
Total kvar 0x2D01 INT32 R 0.001kvar/1kvar -Pmax to Pmax
Total kVA 0x2D02 UINT32 R 0.001kVA/1kVA 0 to Pmax
Total PF
3
0x2D03 UINT16 R 0.001 0 to 1000
Minimum real-time auxiliary values (M)
Reserved 0x2E00 UINT32 R 0
Neutral current 0x2E01 UINT32 R 0.01A 0 to Imax
Frequency 0x2E02 UINT16 R 0.01Hz 0 to 10000
4
Maximum real-time values per phase (M)
Voltage L1/L12
6
0x3400 UINT32 R 0.1V/1V 0 to Vmax
Voltage L2/L23
6
0x3401 UINT32 R 0.1V/1V 0 to Vmax
Voltage L3/L31
6
0x3402 UINT32 R 0.1V/1V 0 to Vmax
Current L1 0x3403 UINT32 R 0.01A 0 to Imax
Current L2 0x3404 UINT32 R 0.01A 0 to Imax
Current L3 0x3405 UINT32 R 0.01A 0 to Imax
Reserved 0
Voltage THD L1/L12 0x3412 UINT16 R 0.1% 0 to 9999
Voltage THD L2/L23 0x3413 UINT16 R 0.1% 0 to 9999
Voltage THD L3/L31 0x3414 UINT16 R 0.1% 0 to 9999
Current THD L1 0x3415 UINT16 R 0.1% 0 to 9999
Current THD L2 0x3416 UINT16 R 0.1% 0 to 9999
Current THD L3 0x3417 UINT16 R 0.1% 0 to 9999
K-Factor L1 0x3418 UINT16 R 0.1 10 to 9999
K-Factor L2 0x3419 UINT16 R 0.1 10 to 9999
K-Factor L3 0x341A UINT16 R 0.1 10 to 9999
Current TDD L1 0x341B UINT16 R 0.1% 0 to 1000
Current TDD L2 0x341C UINT16 R 0.1% 0 to 1000
Current TDD L3 0x341D UINT16 R 0.1% 0 to 1000
Maximum real-time total values (M)
Total kW 0x3500 INT32 R 0.001kW/1kW -Pmax to Pmax
Total kvar 0x3501 INT32 R 0.001kvar/1kvar -Pmax to Pmax
Total kVA 0x3502 UINT32 R 0.001kVA/1kVA 0 to Pmax
Total PF
3
0x3503 UINT16 R 0.001 0 to 1000
Maximum real-time auxiliary values (M)
Reserved 0x3600 UINT32 R 0
Neutral current 0x3601 UINT32 R 0.01A 0 to Imax
Frequency 0x3602 UINT16 R 0.01Hz 0 to 10000
4
Maximum demands (M)
Max. volt demand L1/L12
6
0x3700 UINT32 R 0.1V/1V 0 to Vmax
Max. volt demand L2/L23
6
0x3701 UINT32 R 0.1V/1V 0 to Vmax
Max. volt demand L3/L31
6
0x3702 UINT32 R 0.1V/1V 0 to Vmax
Max. ampere demand L1 0x3703 UINT32 R 0.01A 0 to Imax
Max. ampere demand L2 0x3704 UINT32 R 0.01A 0 to Imax
Max. ampere demand L3 0x3705 UINT32 R 0.01A 0 to Imax
Reserved 0x3706-
0x3708
UINT32 R 0
Max. sliding window kW import demand 0x3709 UINT32 R 0.001kW/1kW 0 to Pmax
Max. sliding window kvar import demand 0x370A UINT32 R 0.001kvar/1kvar 0 to Pmax
Max. sliding window kVA demand 0x370B UINT32 R 0.001kVA/1kVA 0 to Pmax
Reserved 0x370C-
0x370E-
UINT32 R 0
Max. sliding window kW export demand 0x370F UINT32 R 0.001kW/1kW 0 to Pmax
Max. sliding window kvar export demand 0x3710 UINT32 R 0.001kvar/1kvar 0 to Pmax
TOU system parameters
Active tariff 0x3C00 UINT16 R 0 to 15
Active profile 0x3C01 UINT16 R 0 to 15
TOU energy register #1
Tariff #1 register 0x3D00 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x3D01 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x3D0F UINT32 R
5
0 to 10
9
-1
