Satec PM172EH series Reference Guide

35
Parameter Point
ID
Type R/W Unit
Range
1
TOU energy register #2
Tariff #1 register 0x3E00 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x3E01 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x3E0F UINT32 R
5
0 to 10
9
-1
TOU energy register #3
Tariff #1 register 0x3F00 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x3F01 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x3F0F UINT32 R
5
0 to 10
9
-1
TOU energy register #4
Tariff #1 register 0x4000 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x4001 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x400F UINT32 R
5
0 to 10
9
-1
TOU energy register #5
Tariff #1 register 0x4100 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x4101 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x410F UINT32 R
5
0 to 10
9
-1
TOU energy register #6
Tariff #1 register 0x4200 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x4201 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x420F UINT32 R
5
0 to 10
9
-1
TOU energy register #7
Tariff #1 register 0x4300 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x4301 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x430F UINT32 R
5
0 to 10
9
-1
TOU energy register #8
Tariff #1 register 0x4400 UINT32 R
5
0 to 10
9
-1
Tariff #2 register 0x4401 UINT32 R
5
0 to 10
9
-1
... ...
Tariff #16 register 0x440F UINT32 R
5
0 to 10
9
-1
TOU maximum demand register #1 (M)
Tariff #1 register 0x4800 UINT32 R
5
0 to Pmax
Tariff #2 register 0x4801 UINT32 R
5
0 to Pmax
... ...
Tariff #16 register 0x480F UINT32 R
5
0 to Pmax
TOU maximum demand register #2 (M)
Tariff #1 register 0x4900 UINT32 R
5
0 to Pmax
Tariff #2 register 0x4901 UINT32 R
5
0 to Pmax
... ...
Tariff #16 register 0x490F UINT32 R
5
0 to Pmax
TOU maximum demand register #3 (M)
Tariff #1 register 0x4A00 UINT32 R
5
0 to Pmax
Tariff #2 register 0x4A01 UINT32 R
5
0 to Pmax
... ...
Tariff #16 register 0x4A0F UINT32 R
5
0 to Pmax
L1/L12 voltage harmonic angles
Harmonic H01 angle 0x6400 INT16 R 0.1 degree -1800 to 1800
Harmonic H02 angle 0x6401 INT16 R 0.1 degree -1800 to 1800
... ...
Harmonic H40 angle 0x6427 INT16 R 0.1 degree -1800 to 1800
L2/L23 voltage harmonic angles
Harmonic H01 angle 0x6400 INT16 R 0.1 degree -1800 to 1800
Harmonic H02 angle 0x6401 INT16 R 0.1 degree -1800 to 1800
... ...
