45
Table 5-21 Setpoint Alarm Status
Bit Description
0 Alarm #1
1 Alarm #2
2 Alarm #3
3 Alarm #4
4 Alarm #5
5 Alarm #6
6 Alarm #7
7 Alarm #8
8 Alarm #9
9 Alarm #10
10 Alarm #11
11 Alarm #12
12 Alarm #13
13 Alarm #14
14 Alarm #15
15 Alarm #16
Bit meaning: 1 = setpoint has been operated
Table 5-22 Self-check Alarm Status
Bit Description
0 Reserved
1 ROM error
2 RAM error
3 Watchdog timer reset
4 Sampling failure
5 Out of control trap
6 Reserved
7 Timing failure
8 Loss of power (power up)
9 External reset (warm restart)
10 Configuration corrupted
11 RTC time-synchronization required
12 Low battery
1
13-15 Reserved
1
Available in Version 4.93.2 or later.
5.11 Reset/Clear Registers
Table 5-23 Reset/Clear Registers
Action Register Type R/W Range
Clear total energy registers 0xA000 UINT16 W 0
Clear total maximum demand registers 0xA001 UINT16 W 0 = all maximum demands
1 = power demands
2 = volt/ampere demands
Clear TOU energy registers 0xA002 UINT16 W 0
Clear TOU demand registers 0xA003 UINT16 W 0
Clear pulse counters 0xA004 UINT16 W 0 = all counters, 1-4 = counter #1 - #4
Clear Min/Max log 0xA005 UINT16 W 0
Clear event log 0xA006 UINT16 W 0
Clear data log 0xA007 UINT16 W 0-7 = data log #1 - #8, 16 = all data logs
Clear waveform log #1 0xA008 UINT16 0
Clear waveform log #2 0xA009 UINT16 0
Reserved 0xA00A UINT16
Restore event log read pointer 0xA00B UINT16 W 0
Restore data log read pointer 0xA00C UINT16 W 0-7 = data log #1 - #8
16-23, 32-34 = monthly profile data log
#7 (the same as 6)
48-55, 64-66 = daily profile data log #8
(the same as 7)
Restore waveform log #1 read pointer 0xA00D UINT16 W 0
