Satec PM172EH series Reference Guide

56
Parameter Register Type
Unit
2
Range
1
Maximum real-time values per phase
Max. Voltage L1/L12
6
0xB200 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB201 UINT32
Max. Voltage L2/L23
6
0xB202 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB203 UINT32
Max. Voltage L3/L31
6
0xB204 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB205 UINT32
Max. Current L1 0xB206 UINT32 0.01A 0 to Imax
Timestamp 0xB207 UINT32
Max. Current L2 0xB208 UINT32 0.01A 0 to Imax
Timestamp 0xB209 UINT32
Max. Current L3 0xB20A UINT32 0.01A 0 to Imax
Timestamp 0xB20B UINT32
Reserved
Max. Voltage THD L1/L12 0xB224 UINT32 0.1% 0 to 9999
Timestamp 0xB225 UINT32
Max. Voltage THD L2/L23 0xB226 UINT32 0.1% 0 to 9999
Timestamp 0xB227 UINT32
Max. Voltage THD L3/L31 0xB228 UINT32 0.1% 0 to 9999
Timestamp 0xB229 UINT32
Max. Current THD L1 0xB22A UINT32 0.1% 0 to 9999
Timestamp 0xB22B UINT32
Max. Current THD L2 0xB22C UINT32 0.1% 0 to 9999
Timestamp 0xB22D UINT32
Max. Current THD L3 0xB22E UINT32 0.1% 0 to 9999
Timestamp 0xB22F UINT32
Max. Current K-Factor L1 0xB230 UINT32 0.1 10 to 9999
Timestamp 0xB231 UINT32
Max. Current K-Factor L2 0xB232 UINT32 0.1 10 to 9999
Timestamp 0xB233 UINT32
Max. Current K-Factor L3 0xB234 UINT32 0.1 10 to 9999
Timestamp 0xB235 UINT32
Max. Current TDD L1 0xB236 UINT32 0.1% 0 to 1000
Timestamp 0xB237 UINT32
Max. Current TDD L2 0xB238 UINT32 0.1% 0 to 1000
Timestamp 0xB239 UINT32
Max. Current TDD L3 0xB23A UINT32 0.1% 0 to 1000
Timestamp 0xB23B UINT32
Maximum real-time total values
Max. Total kW 0xB280 INT32 0.001kW/1kW -Pmax to Pmax
Timestamp 0xB281 UINT32
Max. Total kvar 0xB282 INT32 0.001kvar/1kvar -Pmax to Pmax
Timestamp 0xB283 UINT32
Total kVA 0xB284 UINT32 0.001kVA/1kVA 0 to Pmax
Timestamp 0xB285 UINT32
Max. Total PF
3
0xB286 UINT32 0.001 0 to 1000
Timestamp 0xB287 UINT32
Maximum real-time auxiliary values
Reserved 0xB300-0xB301 0
Max. Neutral current 0xB302 UINT32 0.01A 0 to Imax
Timestamp 0xB303 UINT32
Max. Frequency 0xB304 UINT32 0.01Hz
0 to 10000
4
Timestamp 0xB305 UINT32
Maximum demands (M)
Max. volt demand L1/L12
6
0xB380 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB381 UINT32
Max. volt demand L2/L23
6
0xB382 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB383 UINT32
Max. volt demand L3/L31
6
0xB384 UINT32 0.1V/1V 0 to Vmax
Timestamp 0xB385 UINT32
Max. ampere demand L1 0xB386 UINT32 0.01A 0 to Imax
Timestamp 0xB387 UINT32
Max. ampere demand L2 0xB388 UINT32 0.01A 0 to Imax
