Satec PM172EH series Reference Guide

41
Trigger parameter Trigger ID Unit
2
Range
1
Time/Date parameters
Day of week 0x0B02 1-7 (1= Sun, 7=Sat)
Year 0x0B03 0 to 99
Month 0x0B04 1 to 12
Day of month 0x0B05 1 to 31
Hour 0x0B06 0 to 23
Minutes 0x0B07 0 to 59
Seconds 0x0B08 0 to 59
High/low real-time values per phase
High current L1 0x0C03 0.01A 0 to Imax
High current L2 0x0C04 0.01A 0 to Imax
High current L3 0x0C05 0.01A 0 to Imax
Low current L1 0x8C03 0.01A 0 to Imax
Low current L2 0x8C04 0.01A 0 to Imax
Low current L3 0x8C05 0.01A 0 to Imax
High/low real-time values on any phase
High voltage
5
0x0E00 0.1V/1V 0 to Vmax
Low voltage
5
0x8D00 0.1V/1V 0 to Vmax
High current 0x0E01 0.01A 0 to Imax
Low current 0x8D01 0.01A 0 to Imax
High voltage THD 0x0E07 0.1% 0 to 9999
High current THD 0x0E08 0.1% 0 to 9999
High K-Factor 0x0E09 0.1 10 to 9999
High current TDD 0x0E0A 0.1% 0 to 1000
High/low real-time auxiliary values
High frequency 0x1002 0.01Hz 0 to 10000
4
Low frequency 0x9002 0.01Hz 0 to 10000
4
High voltage unbalance
7
0x1003 1% 0 to 300
High/low average values per phase
High current L1 0x1103 0.01A 0 to Imax
High current L2 0x1104 0.01A 0 to Imax
High current L3 0x1105 0.01A 0 to Imax
Low current L1 0x9103 0.01A 0 to Imax
Low current L2 0x9104 0.01A 0 to Imax
Low current L3 0x9105 0.01A 0 to Imax
High/low average values on any phase
High voltage
5
0x1300 0.1V/1V 0 to Vmax
Low voltage
5
0x9200 0.1V/1V 0 to Vmax
High current 0x1301 0.01A 0 to Imax
Low current 0x9201 0.01A 0 to Imax
High/low average total values
High total kW import 0x1406 0.001kW/1kW 0 to Pmax
High total kW export 0x1407 0.001kW/1kW 0 to Pmax
High total kvar import 0x1408 0.001kvar/1kvar 0 to Pmax
High total kvar export 0x1409 0.001kvar/1kvar 0 to Pmax
High total kVA 0x1402 0.001kVA/1kVA 0 to Pmax
Low total PF lag 0x9404 0.001 0 to 1000
Low total PF lead 0x9405 0.001 0 to 1000
High/low average auxiliary values
High neutral current 0x1501 0.01A 0 to Imax
High frequency 0x1502 0.01Hz 0 to 10000
4
Low frequency 0x9502 0.01Hz 0 to 10000
4
High voltage unbalance
7
0x1503 1% 0 to 300
High present demands
High volt demand L1/L12
5
0x1600 0.1V/1V 0 to Vmax
High volt demand L2/L23
5
0x1601 0.1V/1V 0 to Vmax
High volt demand L3/L31
5
0x1602 0.1V/1V 0 to Vmax
High ampere demand L1 0x1603 0.01A 0 to Imax
High ampere demand L2 0x1604 0.01A 0 to Imax
High ampere demand L3 0x1605 0.01A 0 to Imax
High block kW import demand 0x1606 0.001kW/1kW 0 to Pmax
High block kvar import demand 0x1607 0.001kvar/1kvar 0 to Pmax
High block kVA demand 0x1608 0.001kVA/1kVA 0 to Pmax
High sliding window kW import demand 0x1609 0.001kW/1kW 0 to Pmax
